Brand New Pilot Spray Dryer

Year 2021

Fully Automatic

Water Evaporation Rate 25-30Kg/Hr @ inlet 190deg C & outlet 90 deg C

Spray Type Atomizer

Connected Load- 7.5 HP

Spray Chamber- SS316 With Insulation and Cladding

Chamber Size – Shell Diameter1950 mm x Shell Height 3000 mm x Cone Height 1720 mm

Hot Air Generator and Hot Air Duct- SS304 With Insulation and Cladding

LPG Gas Fired Burner- 1,00,000Kcal, 2 Stage

Feed Tank- SS316, 150 Lit

Feed Pump

Feed Piping- SS316

Air Distributor- SS304

Powder Duct- SS316

Cyclone Separator- SS316

ID Blower- MS

FD Blower- MS

Operating Control Panel

Skid Mounted Assembly
